Slitting Lines
Slitting Lines from FERRO INDUSTRIES are highly productive and are of State of Art for precision slitting of coil metal.
Our Slitting Lines are designed to slit all types of thin gauge strips to extremely close tolerances. These lines basically consist of Coil handling, Strip processing and Scrap management equipment.
Our Slitting Lines come in a Singe loop, Double loop and Pull through configurations.
Capacities extend from strip thickness of 0.1mm to 14mm
Strip widths of 200mm to 2000mm and coil weight from 1 tonne to 30 tonnes.
Technically what one could expect the unique concept of precision alignment and adjustment of arbours together with high precision roller bearings they rotate on .This didn’t come naturally at one go but took a lot of experimenting, traveling, upgrading and risks to make this concept trouble free and the best.
Characterstics and Features of Our Slitting Lines
- Automatic Strip Threading
- Minimum Burr on strip
- High running accuracy of knife at arbours
- Constant parallel distance between the last Deflector roll and recoiler drum
- Straight edged recoiling
- Capacity to run upto 100mts/min
- Economic efficency due to high automation level.
PRODUCT RANGE
| S.NO. | WIDTH | THICKNESSRANGE | COIL WEIGHT | MATERIAL |
|---|---|---|---|---|
| 1 | 200mm | 0.3 to 3 mm | Upto 2 Tonnes | Cold Rolled Mild Steel,Aluminum,Copper ,Brass |
| 2 | 500mm | 0.3 to 6 mm | Upto 7.5 Tonnes | Cold Rolled Mild Steel,Aluminum,Copper ,Brass |
| 3 | 1250mm | 0.3 to 6 mm | 10 Tonnes | Cold Rolled Mild Steel,Aluminum |
| 4 | 1250mm | 0.3 to 6 mm | 20 Tonnes | Cold Rolled Mild Steel |
| 5 | 2000mm | 0.3 to 6 mm | 30 Tonnes | Cold Rolled Mild Steel |
| 6 | 2000mm | 3 mm to 12 mm | 30 Tonnes | Hot Rolled Mild Steel |
